Garmin echoMAP UHD 62CV eco / plotter 6 "

  • Code: 010-02687-00
€ 1.169,00 € 1.300,00 -10%
CHOOSE THE TRANSDUCER
you chose:

Garmin echoMAP UHD 62CV eco / GPS 6 "

The new ECHOMAP ™ UHD series combo chartplotter, available with a bright 6 ”color display, features Ultra High-Definition, Traditional CHIRP, CHIRP ClearVü ™ technology.

ENTER THE GARMIN WORLD
The new ECHOMAP ™ UHD series combo chartplotter, available with a bright 6 ”color display, features Ultra High-Definition, Traditional CHIRP, CHIRP ClearVü ™ technology.
See what's beneath the boat in incredible detail with an optional transducer
Compatible with BlueChart® g3 & g3 Vision® HD and AutoGuidance features
Manage your browsing experience wherever you are
Create your maps anywhere and customize them according to your needs

OPTIONAL TRANSDUCER BUNDLE
Select the transducer bundle to add a GT24 transducer to Ultra High-Definition ClearVü scanning sonars, which show clear images of what lies beneath the boat. You will also be able to use the traditional wide-range CHIRP sonar for perfect distinction of obstacles.




CARTOGRAPHS AND MAPS
The new ECHOMAP ™ UHD series combo chartplotters feature built-in Wi-Fi® connectivity that allows access to ActiveCaptain ™, a new world of content that allows you to: consult, purchase, update and synchronize BlueChart® g3 and g3 cartography ® g3 Vision with integrated Navionics® content.

QUICKDRAW CONTOURS
Create custom fishing maps with 1 'profiles on-screen. Keep your data to yourself or share it with the QuickDraw ™ community on Garmin Connect ™.

Packaging
echoMAP UHD 62CV
Power / data cable
Quick release support
Flush mounting kit
Brackets for installation on the stern or on electric motor
NMEA 2000 cable
Fast guide
General
DIMENSIONS 21.8 x 13.0 x 6.2 cm
SCREEN DIMENSIONS, WXH 13.7 x 7.7 cm; 15.2 cm (6.2 ") diagonally
SCREEN RESOLUTION, WXH 480 x 800 pixels
SCREEN TYPE WVGA display
WEIGHT 0.7 kg
IPX7 WATERPROOF CLASSIFICATION
POWER CONSUMPTION 12 W
GPS ANTENNA Internal or external on the NMEA 2000 network
MOUNTING OPTIONS On bracket or recessed
RECEIVER 5 Hz
GARMIN MARINE NETWORK ™ DOORS None

Maps and memory
PRELOADED CARTOGRAPHY World basemap
EXTERNAL MEMORY 1 microSD ™ card; with maximum capacity 32 GB
WAYPOINTS 5000
COURSES THAT CAN BE STORED 100
TRACK LOG 50,000 points; 50 saved tracks

Functions for outdoor activities
TIDAL DATA

Functions of the chartplotter
COMPATIBLE WITH GARMIN BLACK-BOXES
COMPATIBLE WITH AIS FUNCTION
COMPATIBLE WITH DSC FUNCTION
ACTIVECAPTAIN COMPATIBLE Yes
SAILING FUNCTIONS

Echosounder features and specifications
DOUBLE FREQUENCY
DOUBLE CONE
TRANSMISSION POWER 500W (RMS) / 4,000W (peak-to-peak)
CHIRP Yes (integrated)
CLEARVÜ Yes with CHIRP (integrated)
SIDEVÜ No
MAXIMUM DEPTH 700 meters @ 77 kHz, fresh water 335 meters @ 77 kHz, salt water
(Depth detection depends on factors such as bottom type and other water conditions)
ZOOM
DATA AND WATER TEMPERATURE GRAPH
REGISTRATION
HISTORICAL

Connections
NMEA 2000® COMPATIBLE
NUMBER OF TRANSDUCER PINS 4
NMEA 0183 INPUT PORTS 1
NMEA 0183 OUTPUT PORTS 1
VIDEO INPUT PORTS None
VIDEO OUTPUT None
WIRELESS CONNECTIVITY Yes

Caratteristiche

Sei interessato ad una offerta privata?
D. Buongiorno vorrei acquistare Garmin echoMAP UHD2 92SV eco/plotter 9", ho un trasduttore modello 520-5MSD0 passante vorrei sapere se e' compatibile e in caso come posso adattarcelo e il costo totale compreso di carte nautiche zona Livorno
R. 31-07-23 Buon pomeriggio, se include la box di adattamento a 12 pin, potrà utilizza il trasduttore Furuno, tagliando il connettore del trasduttore: https://www.painestore.it/garmin_box_trasduttori_12_pin_arancio_/fili_liberi In caso di conferma, mi faccia sapere sempre via mail così gestisco il l'ordine. Cordiali saluti. Luigi Bianchi
D. buonasera, qual'è la differenza fra l'echomap uhd 92sv e l'echomap uhd2 92sv? Inoltre il GT51 va bene per entrambi? Grazie.
R. 20-02-23 Buongiorno, la versione UHD2 è l'ultima uscita, stesse caratteristiche della precedente, ha in più solo la possibilità di condivisione eco via WiFi con altro echoMAP UHD2 e risoluzione 1024 x 600 pixel per UHD2 contro 800 x 400 pixel per 92SV UHD. Il GT51 è compatibile su entrambi. Cordiali saluti. Luigi Bianchi
