General |
|
| Colors | Black |
|---|---|
| Usage | Freshwater, brackish water and salt water |
| Mounting style | Scissor support |
| Maximum displacement | 100 kg ISO 13342 compliant with 36V high efficiency propeller 80 kg ISO 13342 compliant with 24V high efficiency propeller |
| Voltage | 24V/36V. |
| Electric guide | |
| Lifting system | Mechanical, double gas spring |
| Integrated compass sensor | |
| Built-in GPS | Yes (Dual-frequency GPS) |
| Warranty | 3 years |
| Waterproof rating | IPX7 |
| Installation position | Bow |
| Remote control included | Yes (included) |
| Compatible with foot controls | Yes (included) |
| Battery indicator | |
| Speed control | Yes (20 steps) |
| Direction indicator light | |
| Bridge stabilizer | Yes (included) |
| Quatix remote control supported | |
| Manual reverse gear control | |
Fishfinder Features and Specifications |
|
| Supported frequencies | Traditional: High amplitude CHIRP (150-240 kHz) ClearVü/SideVü: 455 kHz, 800 kHz, 1000 kHz |
|---|---|
| Transmission power | Traditional: 350 W ClearVü/SideVü: 500 W |
| Maximum depth | CHIRP Sonar: 800 feet freshwater ClearVü: 400' SideVü: 500' |
| Depth/Speed/Temperature | Depth and temperature |
| Number of pins | 12 pin (orange connector) |
Autopilot functions |
|
| Completing the route | |
|---|---|
| Mooring point | |
| Smart anchoring functions | |
| Anchor locking system | |
| Maintaining direction | |
| Cruise control | |
| Gesture functions | Yes (manual+, direction hold+, slow advance+) |
Pedal features |
|
| Dimensions | 12" x 9" x 4 1/2" (L x W x H) |
|---|---|
| Wireless communication | |
| Power supply installation | Power supply via cable or 12V/24V/36V battery (2 AA) |
| AA battery life | A season |
| Waterproof rating | IPX7 |
| Pedal sensitivity | |
Remote control functions |
|
| Screen size | Diameter 30.2 mm (1.2") |
|---|---|
| Screen resolution | 240 x 240 pixel |
| Screen type | Color, anti-reflective, transflective MIP (Memory-In-Pixel) |
| Chartplotter programmable keys | |
| Checking the autopilot functions | |
| Waterproof rating | IPX7 |
| BATTERY LIFE | Typical use with backlight at minimum, 43 weeks |
| Floats | |
