General | |
Dimensions | 10″/12″ |
|---|---|
Colors | White Sport or Grey Sport |
Physical dimensions (diameter) | 10": 10.83" (275 mm) 12": 14.02" (356 mm) |
Physical Dimensions (Depth) | 10″: 275 mm (10.83″) 12″: 356 mm (14.02″) |
Weight | 10″: 6.1 kg (13.4 lbs) 12″: 12.63 kg (27.8 lbs) |
Waterproof and dustproof rating | IP66/IP67 |
Speaker type | Subwoofer |
Continuous power management (RMS) | 10″: 300 W 12″: 700 W |
Sensitivity (SPL at 1 W/1 m) | 86 dB |
Frequency response (+/- 3 dB) | 10″: 30 Hz-2 kHz 12″: 20 Hz-2 kHz |
Nominal impedance | 4 Ω |
Recommended amplifier power (RMS) | 10″: 50-300 W 12″: 200-700 W |
LED lighting | Yes - CRGBW (5 colors) |
LED supply voltage | 10.8-16 VDC |
LED load current at 14.4V DC (max) | 10″: 190 mA per color 12″: 270 mA per color |
Operating temperature | 0 to 50°C (32 to 122°F) |
Cone material | Polypropylene cone with rubber coating |
Warranty | 3 years |
Electrical characteristics | |
Safe distance from the compass | 10″: 410 cm (13.45 ft) 12″: 580 cm (19.03 ft) |
|---|---|
Connections | |
Speaker connections | 2-way (2-pin, audio positive and negative), waterproof, 150mm (5.9") connector or 6.3mm (0.25") positive and 6.3mm (0.25") negative male spade connectors |
|---|---|
LED connection | 150mm (5.9") 6-Way Waterproof Connector (6-Pin, CRGBW & Ground) |
Mounting dimensions | |
Assembly template | 10″: 223 mm (8.78″) 12″: 301 mm (11.85″) |
|---|---|
Mounting depth | 10″: 135 mm (5.31″) 12″: 198 mm (7.80″) |
Front grille protrusion | 10″: 45 mm (1.77″) 12″: 55 mm (2.17″) |
