General
|
|
|
Dimensions
|
10″/12″
|
|---|---|
|
Colors
|
White Sport or Grey Sport
|
|
Physical dimensions (diameter)
|
10": 10.83" (275 mm)
12": 14.02" (356 mm) |
|
Physical Dimensions (Depth)
|
10″: 275 mm (10.83″)
12″: 356 mm (14.02″) |
|
Weight
|
10″: 6.1 kg (13.4 lbs)
12″: 12.63 kg (27.8 lbs) |
|
Waterproof and dustproof rating
|
IP66/IP67
|
|
Speaker type
|
Subwoofer
|
|
Continuous power management (RMS)
|
10″: 300 W
12″: 700 W |
|
Sensitivity (SPL at 1 W/1 m)
|
86 dB
|
|
Frequency response (+/- 3 dB)
|
10″: 30 Hz-2 kHz
12″: 20 Hz-2 kHz |
|
Nominal impedance
|
4 Ω
|
|
Recommended amplifier power (RMS)
|
10″: 50-300 W
12″: 200-700 W |
|
LED lighting
|
Yes - CRGBW (5 colors)
|
|
LED supply voltage
|
10.8-16 VDC
|
|
LED load current at 14.4V DC (max)
|
10″: 190 mA per color
12″: 270 mA per color |
|
Operating temperature
|
0 to 50°C (32 to 122°F)
|
|
Cone material
|
Polypropylene cone with rubber coating
|
|
Warranty
|
3 years
|
|
Electrical characteristics
|
|
|
Safe distance from the compass
|
10″: 410 cm (13.45 ft)
12″: 580 cm (19.03 ft) |
|---|---|
|
Connections
|
|
|
Speaker connections
|
2-way (2-pin, audio positive and negative), waterproof, 150mm (5.9") connector or 6.3mm (0.25") positive and 6.3mm (0.25") negative male spade connectors
|
|---|---|
|
LED connection
|
150mm (5.9") 6-Way Waterproof Connector (6-Pin, CRGBW & Ground)
|
|
Mounting dimensions
|
|
|
Assembly template
|
10″: 223 mm (8.78″)
12″: 301 mm (11.85″) |
|---|---|
|
Mounting depth
|
10″: 135 mm (5.31″)
12″: 198 mm (7.80″) |
|
Front grille protrusion
|
10″: 45 mm (1.77″)
12″: 55 mm (2.17″) |
