POYNTING OMNI-496

(0)


Faq
Any questions about this product?
You'll find the answers you're looking for HERE
€ 206,18

POYNTING OMNI 496 v1-01

1X WIFI Omnidirectional Antenna 2400-2500-3300-3800-5000-6000 Mhz

The OMNI-496 is a dual-band omnidirectional Wi-Fi antenna developed by Poynting Antennas. The antenna can connect to any Wi-Fi access point, whether it's a router or a router. The antenna can overcome channel saturation and provide the ultimate in Wi-Fi performance and flexibility. The OMNI-496 is an IP68 marine version of its urban, industrial, and commercial counterpart, the OMNI-296. The antenna operates in two frequency bands, 2.4 GHz and 5 GHz, offering excellent spectrum utilization. The antenna has a maximum gain of 6 dBi in the 2.4 GHz band and 7.5 dBi in the 5 GHz band, offering the best performance with reliable connections. The antenna has a female N-type connector at its base that can be terminated with a cable of the desired type and length.

Characteristics :

Frequency bands: 2400 -2500 MHz 3400 - 3800 MHz 5000 - 6000 MHz
Gain (max): 6 dBi @ 2400-2500 MHz 7 dBi @ 3400-3800 MHz 7.5 dBi @ 5000-6000 MHz
VSWR: ≤2.5:1 Feed power handling: 10W
Input impedance: 50 Ohm (nominal)
Coax cable loss: Optional cable dependent
DC short: Yes

Package Contents:

Antenna: A-OMNI-0496
Mounting bracket: Marine Adapter (1'' -14 TPI) & L-bracket (Ø30-50mm Pole)

Dimensions:

Product dimensions 560 mm x 75 mm (Incl. BRKT-40)
Packaged dimensions: 580mm x 95mm x 95mm
Weight: 0.57 kg Packaged weight: 1.3 kg
Radome material: UV Stable Marine ASA
Radome colour: Brilliant White Pantone P 179-1 C
Mounting Type: Standard 1'' -14 TPI marine mount & Wall/pole mount
Environmental Specifications, Certification & Approvals Wind Survival: ≤186 km/h
Temperature Range (Operating): -40°C to +80°C
Environmental Conditions: Outdoor/Indoor Water ingress protection ratio/standard: IP 68 Salt Spray: MIL-STD 810F/ASTM B117
Operating Relative Humidity: Up to 98% Storage Humidity: 5% to 95% - non-condensing
Storage Temperature: -40°C to +80°C
Enclosure Flammability Rating: UL 94-HB
Impact resistance: IK 08
Product Safety & Environmental: Complies with CE and RoHS standards
D Buongiorno, a bordo ho un router PEPWAVE Max Transit Ltea e vorrei sapere se l’antenna in oggetto è compatibile con il router e che tipo di cavo devo acquistare e relativi attacchi. Più o meno fino a che distanza dalla costa funziona? Grazie.
R Dimenticavo, per i cavi usi questi: https://www.painestore.it/ultraflex_5_mep Fino a 10-15 metri Connettore: https://www.painestore.it/mep_conn_pl_maschio_solder_type_7_3mm_co_uhf_7m-s-evo
R Buongiorno, Per servire il suo max transit duo (due modem LTE ) con 4 prese sma occorre il modello 402 link sotto: https://www.painestore.it/poynting_omni402 In aggiunta per la funzione wifi potrebbe integrare con la 496 . La portata del segnale LTE è teoricamente di 10-15 miglia degradando la velocità in proporzione alla distanza dalla costa .Ho effettuato connessioni per scambio di email fino a 25 miglia . Per la funzione WIFI per collegare i sistemi dei Marina consideri 500-600 metri Cordiali saluti Marco
