Connections
Diet
NMEA2000 integration with AIS, autopilot, navigation instruments, engines, tank sensors and VHF
Wi-Fi connection for Quantum radar
High CHIRP transducers
Compatible with the CPT-S family of transom and thru-hull transducers
GENERAL SPECIFICATIONS
Optical bonded LCD display size
Display resolution 800 x 480 WVGA 1,280 x 800 WXGA
Non-Touch Display Type
Brightness 1,500 nit
PHYSICAL CHARACTERISTICS
Overall dimensions W x H x D (mm) 287 x 161 x 62 mm
Product weight (kg) 5.0
IPx6 and IPx7 water infiltration protection
Operating temperature range -25 ° C to + 55 ° C (-13 ° F to 131 ° F)
Storage temperature range -30 ° C to +70 ° C (-22 ° F to +158 ° F)
SENSORS
Integrated GNSS / GPS GPS / GLONASS
Sonar type (built-in) Single channel High CHIRP sonar with 9-pin connector. Supports transom and thru CPT-S transducers
Sonar Depth CHIRP Sonar = 274 m (Theoretical)
Radar Only compatible with Wi-Fi connection
Quantum wireless CHIRP
Doppler radar N / A
MARPA N / A
NETWORK CONNECTION
NMEA 2000 1 NMEA2000 port (DeviceNet microC)
Supported NMEA2000 network connection INPUT: NMEA2000 compatible engines (maximum 2) | NMEA2000 Compatible Tank Sensors (Max 4) | Heading sensor (for paper stabilization)
OUTPUT: GPS (for VHF and DSC rescue). Waypoints, routes and XTE for autopilot. Share waypoints and routes between Element displays
SeaTalkng Requires A06045 Female (F) DeviceNet adapter cable - 400mm
Wi-Fi WiFi - 802.11 b / g / n
OTHER SPECIFICATIONS
Raymarine LightHouse NC2 cartography, Navionics, C-MAP Essentials, C-MAP 4D MAX + and compatible with all charts listed in the Raymarine chart store.
Tides and Currents Requires LightHouse LNC2, Navionics or * C-MAP
Raymarine RealBathy and Navionics SonarChart Live echosounder mapping
Waypoints / Routes / Tracks 5,000 waypoints / 200 waypoint groups / 150 routes - 250 waypoints max / 15 tracks - 10,000 track points max
External Memory 1 x microSD slot
