PREMIUM TOUCHSCREEN DISPLAY PERFECTLY READABLE UNDER DIRECT SUNLIGHT
PROCESSING POWER UP TO 7 TIMES FASTER THAN PREVIOUS GENERATIONS
GET UNPARALLELED CLARITY ON A 4K SCREEN
SUPPORTS GARMIN NAVIONICS+ CHARTS WITH AUTO GUIDANCE+ TECHNOLOGY
GIGABIT SPEED ON THE GARMIN BLUENET NETWORK
INTEGRATE WITH VARIOUS CHARTPLOTTERS, CAMERAS AND MORE
|
General
|
|
|
Dimensions
|
33.5cm x 23.4cm x 9.1cm (13.2″ x 9.19″ x 3.56″)
|
|---|---|
|
Weight
|
4.13 kg (9.1 lbs)
|
|
Waterproof rating
|
IPX7
|
|
Touch screen
|
|
|
Screen type
|
4K, IPS; Mini LED backlight (local dimming)
|
|
Display size
|
29.4 cm x 16.5 cm x 33.7 cm diagonal (11.57″ x 6.50″ x 13.27″ diagonal)
|
|
Display resolution
|
3840 x 2160 pixel
|
|
Mounting options
|
On bracket, flush or recessed
|
|
Key assist buttons
|
Touch screen
|
|
Viewing capability with polarized lenses
|
|
|
Maps and memory
|
|
|
External memory
|
2 microSD cards (on the back of the product)
|
|---|---|
|
USB card reader support
|
|
|
Waypoint
|
5000
|
|
Track points
|
50,000
|
|
Traces
|
50 saved tracks
|
|
Memorable paths
|
100
|
|
Sensors
|
|
|
GPS
|
|
|---|---|
|
GLONASS
|
|
|
Galileo
|
|
|
BeiDou
|
|
|
It has a built-in receiver
|
|
|
Receiver
|
10 Hz
|
|
NMEA 2000 compatible
|
|
|
NMEA 0183
|
|
|
Supports WAAS
|
|
|
Supports multi-band and multi-constellation GPS
|
|
|
Optional map support
|
|
|
BlueChart g3
|
|
|---|---|
|
BlueChart g3 Vision
|
|
|
LakeVü g3
|
|
|
LakeVü g3 Ultra
|
|
|
Garmin Navionics+
|
|
|
Garmin Navionics Vision+
|
|
|
TOPO 100K
|
|
|
Standard mapping
|
|
|
Garmin Quickdraw Contours
|
|
|
Cartography support
|
|
|
Chartplotter functions
|
|
|
Garmin SmartMode compatible (customizable monitor presets)
|
|
|---|---|
|
Compatible with AIS function
|
|
|
Compatible with DSC function
|
|
|
Supports FUSION-Link compatible radios
|
|
|
GCV Black Box Sonar Support
|
|
|
ActiveCaptain compatible
|
Yes
|
|
Supports voice commands
|
|
|
GRID (Garmin Remote Input Device) compatible
|
|
|
Compatible with GRID 20
|
|
|
Wireless Connectivity
|
|
|
Sailing functions
|
|
|
Voice audio alerts
|
|
|
OneHelm Support
|
|
|
Electrical characteristics
|
|
|
POWER INPUT
|
10 to 32 V DC
|
|---|---|
|
Typical current draw at 12V DC
|
3.6 A
|
|
Maximum current draw at 12V DC
|
4.14 A
|
|
Maximum power consumption at 10 V DC
|
44 W
|
|
Fishfinder Features and Specifications
|
|
|
View depth sounder
|
|
|---|---|
|
Traditional echo sounder (dual frequency/beam)
|
Yes (with GCV black box, sold separately)
|
|
Integrated xCHIRP support
|
Yes (with compatible black box)
|
|
Integrated RapidReturn support
|
Yes (with compatible black box)
|
|
ClearVü
|
Yes (with compatible black box)
|
|
SideVü
|
Yes (with compatible black box)
|
|
Panoptix Fishfinder
|
|
|
LiveScope
|
|
|
Connections
|
|
|
NMEA 2000 ports
|
1
|
|---|---|
|
NMEA 0183 Input Ports
|
1
|
|
NMEA 0183 Output Ports (Tx)
|
1
|
|
Video input ports
|
1 (composite BNC); 1 HDMI (HDCP compliant)
|
|
Video output
|
1 HDMI
|
|
J1939 Doors
|
1
|
|
Garmin BlueNet Network Ports
|
2
|
|
USB ports
|
Yes (1x USB-C)
|
|
Bluetooth Call
|
|
|
ANT (Connectivity)
|
|
|
Garmin Wi-Fi network (local connection)
|
|
|
Wi-Fi frequency bands
|
2.4 GHz & 5 GHz
|
|
Audio output
|
|
