Characteristics: Cellular Frequency bands: 698-960 MHz
1710-2700 MHz
3200-3800 MHz
Gain (max) Port 1 & 2: -1dBi @ 698-960 MHz 6dBi @
1710-2700 MHz 6dBi @
3200-3800 MHz
VSWR Port 1 & 2: ≤2.5:1 over 85% of the band Feed power handling: 10 W
Input impedance: 50 Ohm (nominal)
Polarisation: Linear Vertical Coax cable loss: 0.56 dB/m @ 900 MHz 0.72 dB/m @ 1800 MHz 1.2 dB/m @ 3000 MHz
DC Short: Yes GPS/Glonass Antenna Electrical Specifications Frequency Range (GPS): 1575.42MHz/1600MHz
Gain (Max): 21+/-2dBi VSWR: ≤1.5:1
DC Voltage: 2.7-3.3 V
DC Current: 5-15mA
Noise Figure: ≤1.5 dB Nominal Impedance: 50 Ω
Polarisation: RHCP Filter Out Band
Attenuation: 12dB Min f0+50MHz, 16dBi Min f0-50MHz
Cable: RTK-031 Connector: SMA male
Voltage: 2.7 - 3.3V Max.
Power-W: 50
Coax cable loss: 0.65 dB/m @ 1500 MHz
